Best DC Fast Charger

Sanwish best DC fast charger passed CE certification, supports European standard and Japanese standard charging protocol. Sanwish best DC fast charger has OCPP cloud platform, so it can be easily managed.
Send Inquiry
Description
Product Introduction



Sanwish's top-of-the-line DC fast chargers have achieved excellent performance and technology, and recently successfully passed the rigorous CE certification. CE certification is an important symbol of product safety, indicating that this charger not only meets European safety regulations, but also has the characteristics of high quality, high reliability and high safety. It is highly compatible and supports charging protocols of European and Japanese standards, which means that users can easily fast charge their electric vehicles in both Europe and Japan.



Even more exciting is that Sanwish's best DC fast charger is also equipped with the OCPP (Open Charge Point Protocol) cloud platform, an open charging point communication protocol that makes the management of chargers extremely convenient. Through this cloud platform, users or administrators can monitor the operation of the charger in real time, including key information such as charging power, charging time, and device status. At the same time, it can also be remotely controlled and set, such as setting charging prices, limiting charging time, etc., providing users with great flexibility and convenience.



In addition, the OCPP cloud platform also has data analysis and reporting functions, which can collect and analyze the usage data of the charger, help users better understand charging needs and device performance, and provide strong data support for future charging network planning and optimization.



In conclusion, Sanwish best DC fast charger will undoubtedly become a leader in the field of electric vehicle charging with its excellent performance, high safety and convenient management functions, providing users with a more efficient, convenient and safe charging experience.









Product features



01  CCS CHARGER&CHADEMO CHARGER

Sanwish best DC fast charger is developed without any unstable factors with high stability, protection level IP55 and OCPP cloud management platform.

02  CCS&CHADEMO&AC

Multi-Standards&Cost-Effective Electric Vehicle Charging Pile Solution.

03  VEHICLE-TO-GRID

We have already overcome the v2g technology and have implemented it.

04  PCR-OCPP

Based on the OCPP protocol, an operation and maintenance system was set up.

05  IP55&CE

Meeting the requirements of the International leading safety standards.



Product parameter



Product Specification

Model

SW-DC240-01

Input voltage

AC380V±15%

Output voltage

DC200-1000V

Power factor

≥0.99

Output current

0-400A (maximum output of single gun 250A)

Output power

240kW

Harmonic content

≤5%

Voltage range

≤±0.5%

Insulation resistance

≥20MΩ

AC leakage protection function

Yes

Noise

≤60dB

Product efficiency

≥95%

Display screen

7-inch color touch screen

Charging interface

Double connector

Communication Interface

Ethernet, 4G (optional)

Charging mode

Automatically fully charging; Charge by time, by power, by amount

Protection level

IP55

Working temperature

-30℃- +70℃

Storage temperature

-40℃- +70℃

Working humidity

5%-95%.No condensation

Working altitude

≤2000m; Derating is required for use above 2000m

Product protection

Anti-moisture, anti-mildew, anti-salt spray

Charging connector life

≥10000 times

Billing method

RFID card tapping/QR code scanning/APP payment (optional)

Backend APP

Ethernet module/4G module (optional)

Product weight

≤240KG

Charging cable

3*95mm²+2*50mm²

Product dimension

800*600*1700mm
